3021 Electrical Insulating Material Phenolic Impregnated Paper Laminate Sheet

Product Description

Quick Details:
Place of Origin: China (Mainland)                                                  Brand Name: XINCHENG
Name: Bakelite phenolic board                                                      Product name: Phenolic Paper Laminate
Model Number: 3021 Bakelite Sheet for transformer(BKL)           Type: 3021 Bakelite phenolic board /sheet
Basic material: Phenolic resin, Insulation Paper                            Application: High Voltage
Material: Kraft paper phenolic resin,impregnated phenolic
Temperature: 120ºC-180ºC                                                         Tensile Strength: ≥104Mpa
Adhesive strength: 3600N                                                            Density: 1.3-1.45g/cm3
Color: Brown,/orange/ Light Green / Natural / Black / Brow        Sample: Sample Avaliable
Size: 1020X2040mm, 1020X1220mm or Customized                 Thickness:0.5-300mm
Standard: IEC60893-2:2003                                                        Sample: Sample Available
Certification: ISO9001:2000 , CE/ROHS                                     Services: OEM,ODM,CNC
Supply Ability: 300 Metric Ton/Metric Tons per Month orange pertinax sheet Bakelite phenolic paper laminate sheet


Product description
phenolic paper is called phenolic laminated sheet.  a hard, dense material made by applying heat and pressure to layers of paper or glass cloth impregnated with phenolic resin. These layers of laminations are usually of cellulose paper, cotton fabrics, synthetic yarn fabrics, glass fabrics or unwoven fabrics. When heat and pressure are applied to the layers, a chemical reaction (polymerization) transforms the layers into a high-pressure thermosetting industrial laminated plastic.
Phenolic Paper Laminated Insulation sheet is made of insulation paper impregnated by phenolic resin.
Phenolic Paper Laminated Insulation Sheet is insulation calss E(120 degree) and has high mechanical properties, widely used as insulating structural parts in electromotor, electrical equipments which request high mechanical properties, also used in transformer oil.It is used for the insulating spare parts of electrical appliances and transformers, high mechanical properties electrical and mechanical devices.
Orange pertinax sheet /bakelite phenolic paper laminate sheet
Orange pertinax sheet /bakelite phenolic paper laminate sheet- natural color is typically orange or black. known as Phenolic paper laminated owns the character of good mechanical strength, anti-static, intermediate electrical insulation. It`s made by insulating paper impregnated with phenolic resin, after baking hot pressing. This product is suitable for high performance requirements of electrical machinery, electrical equipment as insulating structural parts, and in the transformer oil. Room temperature electrical properties with good machining performance, the proportion is 1.5, warpage 3 ‰ maximum, with excellent electrical, mechanical and processing properties.

Feature:
Bakelite sheet feature: good electrical properties and good machining performance under room temperature, the density is 1.45 g/cm3, angularity  3 , with excellent electrical, mechanical and processing properties. It can be used in transformer oil.
1.Good electrical properties at normal temperature, insulation, no static
2.Good machining performance, Wearable
3.High temperature, heat resistance of 130 °C
4.Fire resistance grade: UL94-HB
5.Color: orange-red, black, natural (kraft paper color)
6.Complete specifications and adequate stock to meet the different needs of customers purchasing
7.Good mechanical properties
8.No water absorption
9.Good surface hardness
10.Abrasion resistance
11.Good insulation

Applications:
paper laminated sheet made of insulation paper impregnated with phenolic resin in heat-rolling and tightening, baking and curing. Widely used as insulating structure parts in motor, electrical equipment and can be used in transformer oil,suitable for being the backup board for PCB, switch cabinet, jag board, die splint, packing machine, high frequency welding machine, forming machine, drilling machine and table grinding machine, etc.
High quality 3021 bakelite paper sheet is made of insulation paper impregnated with phenolic resin in heat-rolling and tightening, baking and curing. Widely used as insulating structure parts in motor, electrical equipment and can be used in transformer oil,suitable for being the backup board for PCB, switch cabinet, jag board, die splint, packing machine, high frequency welding machine, forming machine, drilling machine and table grinding machine, etc.

Phenolic paper laminated sheet Widely apply to components in motor, electrical equipment and insulation system which has high requirement on mechanical property. It has good mechanical strength. It also apply to PCB drilling backing sheet, distribution switch box, fixture board, mould plate, high voltage and low-voltage distribution cabinet, packer, electric comb, motor, machinery mold, PCB, ICT fixture, forming machine, drilling machine,surface grinding plate, transformer oil.
1.Insulation materials for fixtures and mould making process
2.Insulated switch and variable resistor for electronic products in switch gear industry, distribution switch box
3.Countertops,top table for engraving machine,cnc router, woodworking machinery.etc
4.Insulating structural parts for High mechanical performance requirements of machinery, electrical equipment
5.Backing plate, base for PCB drilling machines, molding machines, Forming Machine,testing machines, testing machine,trial machine,fixture board, mould plate, high voltage and low-voltage distribution cabinet, packer, electric comb, motor, machinery mold, ICT fixture.
6.Chemical machinery parts, general machinery parts
7.Gears, generators, pads, bases, baffles, generator, transformer, fixture inverter, motor and electric insulation component.
8.Distribution box, fixture board, the mould plate, high and low voltage distribution box, packing machine insulation parts.
9.Mold making, drilling machine, mesa grinding pads etc.

TECHNICAL OF BAKELITE SHEET
No.ItemUnitIndex value
1Color Orange/black
2Densityg/cm31.30-1.45
3Coefficient of linear thermal expansionKx10
4Shock strength ≥15
5Combustibility(UL94)HB94
6Vertical bending strengthMPa≥120
7Vertical compression strengthMPa≥250
8Tensile strengthMPa≥104
9Impact strengthKJ/m≥67
10Adhesive strengthN≥3600
11Insulation Resistance after soakingΩ1.0*108
12Vertical electric strengthKV/m≥12.1
13Parallel breakdown voltageKV≥10
14Relative dielectric constant(1MHz/50Hz) ≤5.5
15 Volume resistanceΩ x cm107~108

TECHNICAL PARAMETER
ITEMUNITVALUE
  30213021B3021C
Densityg/cm31.30~1.451.30~1.451.30~1.45
Heat stabilityºC---
Thickness 20mm 115115115
Thickness >20mm 90--
Flexural strengthMPa1209090
Tensile strengthMPa100--
adhesion force N363039403740
Insulation resistance parallel to laminationΩ---
Under normal condition 1×1091×1091×109
In case of humidity 1×1071×1061×106
Voltage endurance perpendicular to lamination in transformer oil 5 min at 20±5ºC≥kV/mm---
Thickness:0.2~1mm 16--
Thickness:1.1~2mm 151412
Thickness:2.1~3mm 13--
Thickness:>3mm 13--
Voltage endurance parallel to lamination in transformer oil 5 min at 20±5ºC≥kV141210
Area of the sheetsmm1020×1220,980×1980,1020×2040 or Customized


More Products we are manufacturing
3020 sheet: suitable for using as insulation structural parts of machinery and electric equipment that require high electrical properties, available in transformer oil.
3021 sheet: suitable for using as insulation structural parts of machinery and electric equipment that require high mechanical strength, available in transformer oil.
3021B sheet, 3021C sheet are two derived types from 3021, with lower properties, and attractive price.
3021TG sheet: primarily intended for mechanical applications and suitable as test board and jig.
3022 sheet :good moisture resistance and are suitable for using as insulation structural parts of machinery and electric equipment under wet condition
3023 sheet : lower loss factor and are suitable for using as insulation structural parts of wireless and electrical equipment.

Grade C sheets is intended for mechanical applications requiring high impact strength. Applications include gears and bearings, it has lower mechanical strength than materials with glass substrates, but has superior impact resistance when compared to paper based products, this material is not as suitable for fine machining as grade L.
Grade CE sheets is intended for use in electrical applications requiring good moisture resistance and good mechanical strength, it has lower mechanical strength than materials with glass substrates, but has superior impact resistance when compared to paper based products, this material is not as suitable for fine machining as LE,CE possesses fairly good dielectric properties and medium dielectric loss.
Grade L sheets is intended for machining and mechanical applications requiring a fine edge detail and appearance is required, it possesses a high density, good moisture resistance, and mechanical strength, it has lower mechanical strength than materials with glass substrates, but has superior impact resistance when compared to paper based products.
Grade LE sheets is intended for electrical applications requiring good moisture resistance, it has lower mechanical strength than materials with glass substrates, but has superior impact resistance when compared to paper based products, it is suitable for fine machining, LE possesses fairly good dielectric properties and medium dielectric loss.

3240 sheet: High mechanical and electrical applications, suitable for insulation structural parts of machinery and electric equipment under wet condition, available in transformer oil and humidity.
3240B sheet and 3240C sheet are similar to 3240, but with lower properties.

3721 & 3721-1
Mechanical and electrical applications; 3721 is better than 3721-1 in  mechanical strength; 3721-1 is an economical product versus 3721.
3725
Similar to NEMA grade LE.
 3840
Similar to IEC grade EPGC41 and DIN grade HGW2375. Mechanical and electrical applications, good moisture resistance. If the   usage is not hindered, it is allowed to have some cracks on top surface or section of rod with diameter more than 25mm.
3841 & 3841F
Similar to NEMA grade G-10 and FR-4 respectively. If the usage is not hindered, it is allowed to have some cracks on top surface or section of rod with diameter more than 25mm.
  Grade G10 sheets exhibits extremely hight mechanical strengths (flexural, impact, and bonding) at room temperature, good dielectric loss and electric strength properties under both dry and humid conditions.
Grade FR4 sheet exhibits extremely high mechanical strength(flexural, impact, and bonding) at room temperature and has good dielectric loss and electric strength properties under both dry and humid conditions.
Grade G11 sheet exhibits extremely high mechanical strengths(flexural, impact) at room temperature, and maintains a minimum of 30.0 ksi flexural strength at 150°C,good dielectric loss and electric strength properties under both dry and humid conditions.
Grade FR5 sheet exhibits good chemical resistance and its heat resistance is better than FR-4,material is intended for use as electrical and electronic insulation where low moisture absorption and high physical strength is needed, it is not recommended for wear applications.

SMC and BMC are abbreviations of respectively Sheet Molding Compound and Bulk Molding Compound. SMC and BMC form a family of structural, fiber reinforces thermosetting resins. SMC and BMC are intermediate materials from which a large variety of products can be manufactured by compression molding or injection molding. Base materials of SMC and BMC are, generally spoken, unsaturated polyester resins, glass and mineral filler materials, such as chalk or aluminum trihyd rate. The composition of the compounds can be adapted to the application where it is used for. Specific properties such as flame retardancy, surface quality and paintability can be achieved by adding specific, functional materials. SMC and BMC product are used in a very broad range of applications.
 Characteristics
High mechanical strength.
Good flame retardancy
Flame retardancy and proof tracking
Excellent dielectricity, high voltage resistance
Low water absorption ratio, Good Dimensional Stability and low warp


Specifications
Regular sizesColor
2500mm*1500mm*3~30mmVarious colors:
White, black, red, green, blue, yellow, orange, etc.
2440mm*1220mm*3~30mm
2000mm*1300mm*3~40mm
2000*1000mm*2~40mm
850*850*2~60mm
Note: Other specifications can be made upon clients' requests.


FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 14 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the free sample if we have ready parts in stock.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery


Packaging & Delivery
Packaging Details: Wrapped with a fraft paper. Then secure them on a pallet or standard export wooden box or according to customers' request.
Port: Qingdao/Shanghai
Lead Time ::7-10days after payment


Please Contact Us
